Security

Tokens authenticate callers; scopes, environments and tenant headers restrict what a token reaches; the network access policy restricts upstream targets.

Authentication ​

API requests require a Bearer token:

Authorization: Bearer your-token-here

Tokens are cryptographically random values, stored hashed in auth.db, and bound to a username for auditing.

Console accounts ​

Roles, recovery and session keys: Console Accounts.

Authorization ​

Scopes and environments ​

Token fields AllowedScopes and AllowedEnvironments restrict a token to endpoints and environments. Patterns: Access Tokens.

Tenant headers ​

Tenant headers restrict a token to the rows, upstream records and files of specific customers: Tenant Headers.

Endpoint-level restrictions ​

Endpoints define their own environments and methods:

{
  "DatabaseObjectName": "SensitiveData",
  "AllowedEnvironments": ["prod"],
  "AllowedMethods": ["GET"]
}

Hidden removes an endpoint from the OpenAPI document and does not restrict access.

A request must pass both the token and the endpoint restrictions. Matrix: Access Tokens.

Network security ​

Upstream hosts ​

Proxy targets are restricted by environments/network-access-policy.json: Network access policy.

Security headers ​

Response headers:

Console pages at /ui also send Cross-Origin-Opener-Policy and Cross-Origin-Resource-Policy (same-origin). Full list: Headers.

Secrets management ​

Plaintext connection strings and authentication values in environment settings.json files are encrypted at the next start (PWENC:...). The chat API key in mcp.db is encrypted. appsettings.json is not rewritten: values there remain plaintext. Keys and replacement: Secret Encryption. Azure Key Vault as a secret source: Environments.

SQL Server permissions ​

Minimum permissions for a Windows Authentication (NTLM) database account under IIS:

USE [master];
GO
IF NOT EXISTS (SELECT 1 FROM sys.server_principals WHERE name = N'DOMAIN\USER_NAME')
BEGIN
    EXEC ('CREATE LOGIN [DOMAIN\USER_NAME] FROM WINDOWS;');
END
GO
USE [YourDatabase];
GO
IF NOT EXISTS (SELECT 1 FROM sys.database_principals WHERE name = N'DOMAIN\USER_NAME')
BEGIN
    CREATE USER [DOMAIN\USER_NAME] FOR LOGIN [DOMAIN\USER_NAME];
END
GO
ALTER ROLE [db_datareader] ADD MEMBER [DOMAIN\USER_NAME];  -- Read tables/views
ALTER ROLE [db_datawriter] ADD MEMBER [DOMAIN\USER_NAME];  -- Write (insert/update/delete)
GRANT EXECUTE TO [DOMAIN\USER_NAME];                       -- Stored procedures
GRANT VIEW DEFINITION TO [DOMAIN\USER_NAME];               -- Schema metadata
GO

Grant only the roles the endpoints use; read-only deployments need only db_datareader.

Logging and auditing ​

Invalid tokens are logged at Debug, rate limit blocks at Warning. Per-request traffic logging with headers and bodies: Health and Logs. Token changes are recorded in the token audit log.

Pre-deployment checklist ​

• HTTPS terminated at IIS or a reverse proxy
• Service account or Application Pool identity with minimum privileges
• Console account with a strong password; legacy PORTWAY_ADMIN_KEY removed
• PORTWAY_KNOWN_PROXIES set to the reverse proxy (client addresses for rate limiting, sign-in lockout and the console network gate)
• Read-only console users hold viewer
• portway.key kept with the deployment and out of shared backups
• Azure Key Vault configured (if applicable)
• Initial token file removed from disk
• Tokens created with specific scopes and environments
• Rate limiting configured
• Firewall rules reviewed
• Security headers verified with a response inspection tool

Compromised token ​

1. Under Access Tokens, rotate the affected token; rotation revokes the old value and issues a replacement.
2. Update the applications that use the token.
3. Enable traffic logging and review requests with the old token value.
4. Record the incident.
